nRF52833 System on Chip

105°C qualified Bluetooth 5.4 SoC supporting Bluetooth Low Energy, Bluetooth mesh, NFC, Thread and Zigbee

The nRF52833 is a general-purpose multiprotocol SoC with a Bluetooth Direction Finding capable radio, qualified for operation at an extended temperature range of -40°C to 105°C. It is the 5th addition to the industry leading nRF52 Series and is built around a 64 MHz Arm Cortex-M4 with FPU, and has 512 KB flash and 128 KB RAM memory available for higher value applications.

The extended 105°C temperature qualification, coupled with a generous amount of memory and dynamic multiprotocol support ensures the nRF52833 is an ideal device for a wide range of commercial and industrial applications, including professional lighting and asset tracking. A 1:4 RAM to Flash ratio and +8 dBm output power make the nRF52833 suitable for advanced wearables or smart home applications where robust coverage is important.

It includes a range of analog and digital interfaces such as NFC-A, ADC, Full-speed 12 Mbps USB 2.0, High-speed 32 MHz SPI, UART/SPI/TWI, PWM, I2S and PDM, and has a 1.7 V to 5.5 V supply voltage range, which enables powering the device from rechargeable batteries or over USB. The two-stage LDO regulator and a DC-DC converter, together with the automated power management system help deliver low power numbers even in more advanced applications.

Ask us about this
Key features
  • 64 MHz Arm Cortex-M4 with FPU
  • 512 KB Flash, 128 KB RAM
  • 2 Mbps, 1 Mbps, Long Range
  • Bluetooth Low Energy
  • Bluetooth Direction Finding
  • Bluetooth mesh
  • Thread, Zigbee
  • +8 dBm TX Power
  • 128-bit AES CCM
  • UART, SPI, TWI, PDM
  • HS-SPI, I2S, PWM
  • 12-bit ADC
  • NFC
  • USB 2.0
Documentation
Downloads

Comparison of our Bluetooth LE SoCs

SoC nRF5340 nRF52840 nRF52833 nRF52832 nRF52820 nRF52811 nRF52810 nRF52805
Bluetooth  5.4 5.4 5.4 5.4 5.4 5.4 5.4 5.4
Thread  Yes Yes Yes Yes Yes
Matter  Yes Yes
Zigbee  Yes Yes Yes Yes
Bluetooth Mesh  Yes Yes Yes Yes Yes
Flash   1 MB + 256 KB 1 MB 512 KB 512/256 KB 256 KB 192 KB 192 KB 192 KB
RAM   512 KB + 64 KB 256 KB 128 KB 64/32 KB 32 KB 24 KB 24 KB 24 KB
CPU   128 MHz Arm Cortex-M33 + 64 MHz Arm Cortex-M33 64 MHz Arm Cortex-M4 with FPU 64 MHz Arm Cortex-M4 with FPU 64 MHz Arm Cortex-M4 with FPU 64 MHz Arm Cortex-M4 64 MHz Arm Cortex-M4 64 MHz Arm Cortex-M4 64 MHz Arm Cortex-M4
High-Speed SPI   Yes Yes Yes
QSPI   Yes Yes
USB   Yes Yes Yes Yes
PWM, PDM, I2S   Yes Yes Yes Yes PWM, PDM PWM, PDM
ADC, Comp  Yes Yes Yes Yes COMP ADC, COMP ADC, COMP ADC
Temp Range -40 to 105 °C -40 to 85 °C -40 to 105 °C -40 to 85 °C -40 to 105 °C -40 to 85 °C -40 to 85 °C -40 to 85 °C
Supply voltage range   1.7 to 5.5 V 1.7 to 5.5 V 1.7 to 5.5 V 1.7 to 3.6 V 1.7 to 5.5 V 1.7 to 3.6 V 1.7 to 3.6 V 1.7 to 3.6 V
Packages   aQFN94

WLCSP95 		aQFN73

WLCSP94 		aQFN73

QFN40

WLCSP76 		QFN48

WLCSP50
QFN40 QFN48

QFN32

WLCSP33
QFN48

QFN32

WLCSP33
WLCSP28
GPIOs   48 48 18-42 32 18 15-32 15-32 10

Compatible PMIC and RF FEM options

nPM1300 PMIC

Power Management IC (PMIC) with unique system management features

The nPM1300 is designed to provide highly efficient power regulation for Nordic’s nRF52 and nRF53 Series, as well as the nRF54L and nRF54H Series wireless multiprotocol Systems-on-Chip (SoC). The PMIC is also suitable for battery charging for applications based on the nRF91 Series systems-in-package (SiPs) for cellular IoT, by using the PMIC’s unregulated output to power the SiP's internal buck regulators.

Devices using the nPM1300 and a compatible SoC or SiP also get access to the Nordic Fuel Gauge, a highly accurate, ultra-low-power way of estimating state-of-charge of rechargeable batteries.

Read more

nPM1100 PMIC

Ultra-small form-factor Power Management IC (PMIC) for charging batteries and power delivery

The nPM1100 is a dedicated power management IC (PMIC) with dual-mode configurable buck regulator and integrated battery charger. It is designed as a complementary component to Nordic’s nRF52® Series and nRF53® Series System-on-Chips (SoCs) to ensure reliable power delivery and stable operation, whilst maximizing battery life through high efficiency and low quiescent currents. It can also be used as a generic PMIC device for any other suitable application. Its extremely compact form factor makes it ideal for advanced wearables, connected medical devices, and other size constrained applications. PCB area usage can be as low as 23 mm2.
Read more

nRF21540 SoC nRF21540 RF FEM

RF front-end module (FEM) for Bluetooth® Low Energy, Bluetooth® mesh, 2.4 GHz proprietary and Thread and Zigbee

Supports Bluetooth® Low Energy, Bluetooth® mesh, Thread and Zigbee (802.15.4) and 2.4 GHz proprietary protocols

Tunable output power in small increments up to +21 dBm

13 dB RX gain with 2.7 dB noise figure

Two antenna ports for antenna diversity

TX gain control via I/Os, SPI, or a combination

-40 °C to 105 °C extended operating temperature range

1.7 to 3.6 V supply range

4x4 mm QFN16 package

Between 6.3-10x range extension when combined with an nRF52 or nRF53 Series SoC
